Why Is My Car Air Con Leaking?

The main reason why your air con is probably leaking

Most of the time, the issue with air con leaking is related to the air conditioning condenser.


​The air conditioning condenser is made up of a series of tubes and fins usually made of aluminum; it looks and functions just like the vehicle's radiator.

The condenser has an inlet and an outlet for the circulation of the Freon gas. The purpose of the condenser is to remove heat from the refrigerant.

As the hot gas passes through the air cooled tubes, the gas condenses into a liquid. The condenser is located in the front of the vehicle and is vulnerable to foreign objects that can hit and puncture it.

Freon is able to leak from any holes in the condenser, causing the air conditioning system to work inefficiently, and eventually to completely stop working.

Because of the high pressures in the Air Con system, damaged condensers need to be replaced rather than repaired.

A regular service of your car air conditioning can help identify even the smallest leaks in time, before the condensers get too damaged, to the point where the only option is to replace them.

The condenser is located at the front of the engine bay, where it has access to cool air. The condenser, much like the radiator, is subject to damage and leaks caused by debris in the air.

Automotive Electrical Designs have the right tools and technical expertise to test your car air con for any blockages and quickly repair any faults to ensure proper functionality and long-term efficiency of your vehicle air conditioning system.
